Price & Specifications

Tap Price for Data Sheet

Frame

MODEL: Fat-bike, folding

MATERIAL: Aluminium alloy, 6061

CUT IT: 16”

TOTAL WEIGHT: 24Kg (about)

AVAILABLE COLOURS: Black / Red,  White / Silver/



Front Fork

TYPE OF FORK: Mechanical front suspension fork with lock



Handlebar

TYPE: In aluminium, wth folding handlebar and adjustable in height

HANDLEBAR: Riser bar



Wheels & Tyres

TIRE: CHAOYANG BIGDADDY 16”x4”

CIRCLE: Aluminium

FRONT HUB.: With disc brake

REAR HUB: With engine and disc brake



Brakes

TYPE BRAKE: To disc

FRONT DISC CALIPER: Mechanics, TEKTRO

REAR DISC CALIPER:Mechanics, TEKTRO

BRAKE LEVER: In aluminium, RADIUS



Gears

GEARING: 7 Speed

FRONT DERAILLEUR: Not present

REAR DERAILLEUR: SHIMANO Tourney / RD-TY300D

SHIFTER: SHIMANO SL-TX30-7R

CROW: Aluminium, single, 1 speed



Motor

MODEL: JABO Motor

TYPE: Direct current without brushes (Brushless)

POWER: 350 Watt

VOLTAGE: 48 Volt

PLACEMENT: Rear wheel



Battery

CAPACITY: 48V 13AH

TYPE CELLS: Lithium Ion (Li-Ion) with PANASONIC elements

AUTONOMY (KM): 40 – 80 Km depending on the engine effort

RECHARGE TIME: 6 – 8 ore (about)

CHARNING CYCLES: 1000 cycles (approx)

PLACEMENT: External, saddle pad, removable

USB PORT: NO



Display Technology

MODEL: KEYDYSP KD21C-KDS

TYPE: Multifunction with display LCD

PAS LEVELS: 5 levels (speed)

CRUISE CONTROL: Yes, max 6Km/h

FUNCTIONS: Battery status indicator, backlight, odometer, pedal assist levels



Other Components

SADDLE: Ergonomic, with central hole

SEAT: Aluminum alloy with quick release

FENDER: Metal, in color

FRONT LIGHT: LED, activated by handlebar

REAR LIGHT: activated by handlebar

PEDALS: Folding, in ABS



FRAME

MODEL: Fat-bike, folding

MATERIAl: Aluminium alloy, 6061

CUT IT: 16”

TOTAL WEIGHT: 24Kg (about)

AVAILABLE COLOUR: Black/ Red, White/ Silver, Green



HANDLEBARS.

TYPE: In aluminium, wth folding handlebar and adjustable in height

HANDLEBAR: Riser bar.





BRAKES.

TYPE BRAKE: To disc

FRONT DISC CALIPER: Mechanics, TEKTRO

REAR DISC CALIPER:Mechanics, TEKTRO

BRAKE LEVER: In aluminium, RADIUS



ENGINE.

MODEL: XIONGDA Motor

TYPE: Direct current without brushes (Brushless)

POWER: 250 Watt

VOLTAGE: 36 Volt

PLACEMENT: Rear wheel.



CONTROLLER.

MODEL: KEYDYSP KD21C-KDS

TYPE: Multifunction with display LCD

PAS LEVELS: 5 levels (speed)

CRUISE CONTROL: Yes, max 6Km/h

FUNCTIONS: Battery status indicator, backlight, odometer, pas levels.



ACCESSORIES.

COMPASS: Not present

CARRIER: In metal (Max 25Kg) optional tribute

CELL PHONE HOLDER: Not present

CLACKSON: Yes.



FRONT FORK.

TYPE OF FORK: Mechanical front suspension fork with lock.



WHEELS.

TYRE: CST 16”x4”

CIRCLE: Aluminium

FRONT HUB.: With disc brake

REAR HUB: With engine and disc brake.



GEARS.

CHANGE RAPORT: 7 Speed

FRONT DERAILLEUR: Not present

REAR DERAILLEUR: SHIMANO Tourney / RD-TY300D

COMANDS: SHIMANO SL-TX30-7R

CROW: Aluminium, single, 1 speed.



BATTERY.

CAPACITY: 36V 10.4AH

TYPE CELLS: Lithium Ion (Li-Ion) with SAMSUNG elements

AUTONOMY (KM): 30 – 60 Km depending on the engine effort

RECHARGE TIME: 6 – 8 ore (about)

CHARNING CYCLES: 1000 cycles(about)

PLACEMENT: External, saddle pad, removable

USB PORT: Yes



OTHER COMPONENTS.

SADDLE: Ergonomic, with central hole

SEAT: Aluminum alloy with quick release

FENDER: Metal, in color

FRONT LIGHTHOUSE: LED, activated by handlebar

REAR LIGHTHOUSE: activated by handlebar

PEDALS: Folding, in ABS.



NOTE.

Cartridge bottom bracket with magnet, 16 “Fat wheels, cushioned fork



FRAME

MODEL: Folding Fat bike

MATERIAL: Aluminium alloy, 6061

SIZE: 20”x 4”

OVERALL WEIGHT: 28Kg (approximately)

AVAILABLE COLOURS: Black, Red,



HANDLEBARS

TYPE: Made of aluminum, with folding handlebars and adjustable height

HANDLEBAR: Adjustable.



BRAKES

TYPE: Disc brakes

FRONT BRAKE CALIPER: Hydraulic, TEKTRO

BACK BRAKE CALIPER: Hydraulic, TEKTRO

BRAKE LEVERS: Made of aluminum, TEKTRO



MOTOR

MODEL: BAFANG Motor

TYPE: DC Brushless

POWER: 500 Watt

VOLTAGE: 48 Volt

LOCATION: Rear wheel



CONTROLLER

MODEL: KEYDYSP KD21C-KDS

TYPE: Multifunction with LCD display

ROTATION SENSOR LEVELS: 5 levels (speed)

CRUISE CONTROL: Yes, max 6Km/h

FUNCTIONS: Battery status indicator, rear light, odometer, rotation sensor levels.



FRONT FORK

TYPE OF FORK: Standard fork.



WHEELS & TYRES

TYRES: 20*2.125”

RIM: Aluminum 34-holes

FRONT HUB: With brake disc

BACK HUB: With motor and brake disc



GEARS

GEARS: 7 Speeds

FRONT DERAILLEUR: No

BACK DERAILLEUR: SHIMANO Tourney / RD-TY300D

CONTROLS: SHIMANO SL-TX30-7R

DERAILLEUR: Aluminum, single, 1 speed.



BATTERY

CAPACITY: 48V 12AH

CELL TYPE: Lithium Ion (Li-Ion) with SAMSUNG elements

AUTONOMY (KM): 30 – 60 Km depending on the engine effort

RECHARGE TIME: 6 – 8 hours (approximately)

RECHARGE CYCLES: 1000 cycles (approximately)

PLACEMENT: External, saddle pad, removable

USB PORT: Yes



OTHER COMPONENTS

SADDLE: Ergonomic

SEAT: Aluminum alloy with quick release

FENDER: Metal

FRONT HEADLIGHT: LED, activated by handlebar

REAR LIGHT: LED, activated by handlebar

PEDALS: Folding, ABS with aluminum body

Frame

MODEL: Fat-Bike, Folding

MATERIAL: Aluminium Alloy, 6061

SIZE: 20”

TOTAL WEIGHT: 35Kg (about)

AVAILABLE COLOUR: Black,



 Wheels & Tyres

TYRES: CHAOYANG 20“ x 4”

RIM: Alloy, 6 spokes, BAFANG

REAR HUB: With disc brake

FRONT HUB: With motor and disc brake



HANDLEBARS

TYPE: In aluminum, with folding handlebar and adjustable height

HANDLEBAR: Riser bar



Front Fork

Suspension fork with locking and unlocking system.



Motor

MODEL: WTA Motor

TYPE: Brushless continuous current (Brushless)

POWER: 250 Watts

VOLTAGE: 48 Volts

LOCATION: Rear wheel



GEARS

GEAR RATIO: 7 Speed

FRONT DERAILLEUR: No

REAR DERAILLEUR: SHIMANO Tourney / RD – TY300D

CONTROLS: SHIMANO ALTUS SL-M310

CROWN: Single, 1 speed, 48 teeth



Controller

MODEL: KEYDYSP KD21C

TYPE: Multifunction with LCD display

PAS LEVELS: 5 levels (speed)

CRUISE CONTROL: Yes, max 6Km / h

FUNCTIONS: Battery level indicator, backlight, odometer, pas levels



Battery

CAPACITY: 48V 13AH

CELL TYPE: Lithium Ion (Li-Ion) with EVE elements

AUTONOMY (KM): 30 – 60 Km depending on the engine effort

RECHARGING TIME: 6 – 8 hours (approximately)

RECHARGE CYCLES: 1000 cycles (approximately)

LOCATION: External, underseat, removable

USB PORT: Yes



ACCESSORIES

COMPASS: Not present

LUGGAGE RACK: Metal (Max 25Kg)

PHONE HOLDER: Not present

CLACKSON: Yes (bell)



Other Components

SADDLE: In “Gel”

SEAT POST: Aluminum alloy with quick release (ZOOM)

MUDGUARDS: Metal, steel (rust free)

HEADLIGHT .: LED, can be activated from the display

REAR LIGHT: LED, can be activated from the display

PEDALS: Folded, in ABS with aluminum body

Frame

MODEL: Fat-Bike, Folding

MATERIAL: Aluminium Alloy, 6061

SIZE: 20”

TOTAL WEIGHT: 29Kg (about)

AVAILABLE COLOUR: Black, White, Red



 Wheels & Tyres

TYRE: CHAOYANG 20″ * 4″

RIM: Aluminum, 34 holes with double reinforced chamber

FRONT HUB: with brake disc

REAR HUB: With engine and brake disc



HANDLEBARS

TYPE: In aluminum, with folding handlebar and adjustable height

HANDLEBAR: Riser bar



Front Fork

Suspension fork with locking and unlocking system.



Motor

MODEL: WTA Motor

TYPE: Brushless continuous current (Brushless)

POWER: 500 Watts

VOLTAGE: 48 Volts

LOCATION: Rear wheel



GEARS

TRANSMISSION REPORTS: 7 Speed MEGA RANGE posteriore

FRONT DERAILLEUR: Not present

REAR DERAILLEUR: SHIMANO Tourney / RD-TY300D

CONTROLS: SHIMANO SL-M310

CROWN: Aluminum, single, 1 speed, 48 teeth



Controller

MODEL: KEYDYSP KD51C-D (central display)

TYPE: Multifunction with LCD display

PAS LEVELS: 5 levels (speed)

CRUISE CONTROL: Yes, max 6Km / h

FUNCTIONS: Battery status indicator, backlight, odometer, pas levels



Battery

CAPACITY: 48V 13AH

CELL TYPE: Lithium Ion (Li-Ion) with EVE elements

AUTONOMY (KM): 30 – 60 Km depending on the engine effort

RECHARGING TIME: 6 – 8 hours (approximately)

RECHARGE CYCLES: 1000 cycles (approximately)

LOCATION: External, underseat, removable

USB PORT: Yes



ACCESSORIES

COMPASS: Not present

LUGGAGE RACK: Metal (Max 25Kg)

PHONE HOLDER: Not present

CLACKSON: Yes (bell)



Other Components

SADDLE: In “Gel”

SEAT POST: Aluminum alloy with quick release (ZOOM)

MUDGUARDS: Metal, steel (rust free)

HEADLIGHT .: LED, can be activated from the display

REAR LIGHT: LED, can be activated from the display

PEDALS: Folded, in ABS with aluminum body

Frame

MODEL: Fat-Bike, Folding

MATERIAL: Aluminium Alloy, 6061

SIZE: 20”

TOTAL WEIGHT: 29Kg (about)

AVAILABLE COLOUR: Grey



Wheels & Tyres

TYRE: CHAOYANG 20″ * 4″

RIM: Aluminum, 34 holes with double reinforced chamber

FRONT HUB: with brake disc

REAR HUB: With engine and brake disc



Steering

TYPE: In aluminum, with folding handlebar and adjustable height

HANDLEBAR: Riser bar



Front Fork

Suspension fork with locking and unlocking system.



Motor

MODEL: WTA Motor

TYPE: Brushless continuous current (Brushless)

POWER: 500 Watts

VOLTAGE: 48 Volts

LOCATION: Rear wheel



Gear Shift

TRANSMISSION REPORTS: 7 Speed MEGA RANGE posteriore

FRONT DERAILLEUR: Not present

REAR DERAILLEUR: SHIMANO Tourney / RD-TY300D

CONTROLS: SHIMANO SL-M310

CROWN: Aluminum, single, 1 speed, 48 teeth



Controller

MODEL: KEYDYSP KD51C-D (central display)

TYPE: Multifunction with LCD display

PAS LEVELS: 5 levels (speed)

CRUISE CONTROL: Yes, max 6Km / h

FUNCTIONS: Battery status indicator, backlight, odometer, pas levels



Battery

CAPACITY: 48V 13AH

CELL TYPE: Lithium Ion (Li-Ion) with EVE elements

AUTONOMY (KM): 30 – 60 Km depending on the engine effort

RECHARGING TIME: 6 – 8 hours (approximately)

RECHARGE CYCLES: 1000 cycles (approximately)

LOCATION: External, underseat, removable

USB PORT: Yes



Accessories

COMPASS: Not present

LUGGAGE RACK: Metal (Max 25Kg)

PHONE HOLDER: Not present

CLACKSON: Yes (bell)



Other Components

SADDLE: In “Gel”

SEAT POST: Aluminum alloy with quick release (ZOOM)

MUDGUARDS: Metal, steel (rust free)

HEADLIGHT .: LED, can be activated from the display

REAR LIGHT: LED, can be activated from the display

PEDALS: Folded, in ABS with aluminum body

Frame

MODEL: Fat-bike, folding
MATERIAL: aluminium alloy, 6061
SIZE: 20”
TOTAL WEIGHT: 30Kg (about)
AVAILABLE COLORS: Black, Orange

Handlebar

TYPE: In aluminum, with folding handlebar and adjustable height
HANDLEBAR: Flat bar.



Brakes

BRAKE TYPE: Disc
FRONT BRAKE CALIPER .: Hydraulic, Shimano
POST BRAKE CALIPER: Hydraulic, Shimano
BRAKE LEVERS: aluminum, Shimano

Motor

MODEL: WTA Motor
TYPE: Brushless continuous current (Brushless)
POWER: 500 Watts
VOLTAGE: 48 Volts
LOCATION: Rear wheel

Controller

MODEL: KEYDYSP KD51C-D
TYPE: Multifunction with LCD display
PAS LEVELS: 5 levels (speed)
CRUISE CONTROL: Yes, max 6Km / h
FUNCTIONS: Battery status indicator, backlight, odometer, pas levels

Accessories

COMPASS: Not present
LUGGAGE RACK: Present
PHONE HOLDER: Not present
CLACKSON: Yes (bell)

Front Fork

TYPE OF FORK: Mechanical suspension fork.

Wheels

TYRE: CHAOYANG 20″*4”
RIM: Aluminum, 34 holes with double reinforced chamber
ANT HUB .: with brake disc
REAR HUB: With engine and brake disc.

Gears

TRANSMISSION REPORTS: 7 Speed MEGA RANGE posteriore
FRONT DERAILLEUR: Not present
REAR DERAILLEUR: SHIMANO Tourney / RD-TY300D
CONTROLS: SHIMANO SL-M310
CROWN: Aluminum, single, 1 speed, 48 teeth

Battery

CAPACITY: 48V 16AH
CELL TYPE: Lithium Ion (Li-Ion) with SAMSUNG elements
AUTONOMY (KM): 30 – 60 Km depending on the engine effort
RECHARGING TIME: 6 – 8 hours (approximately)
RECHARGE CYCLES: 1000 cycles (approximately)
LOCATION: Integrated in the frame
USB PORT: No

Other Components

SADDLE: In “Gel”
SEAT POST: Aluminum alloy with quick release (ZOOM)
MUDGUARDS: Plastic
HEADLIGHT .: LED, can be activated from the display
REAR LIGHT: LED, can be activated from the display
PEDALS: Folded, in ABS with aluminum body

FRAME

MODEL: Folding fat bike

MATERIAL: Aluminum, 6061

SIZE: 20”

TOTAL WEIGHT: 35Kg (approximately)

AVAILABLE COLORS: Wrinkled black



HANDLEBARS

TYPE: Made of aluminum, with folding handlebars and adjustable height

HANDLEBAR: Riser bar.



BRAKES

TYPE: Disc brakes

REAR BRAKE CALIPER: Hydraulic, TEKTRO

FRONT BRAKE CALIPER: Hydraulic, TEKTRO

BRAKE LEVELS: In aluminum, TEKTRO



MOTOR

MODEL: BAFANG Motor

TYPE: Direct current without brushes (Brushless)

POWER: 750 Watt

VOLTAGE: 48 Volt

PLACEMENT: Rear wheel.



CONTROLLER

MODEL: KEYDYSP KD21C

TYPE: Multifunction with LCD display

PAS LEVELS: 5 levels (speed)

CRUISE CONTROL: Yes, max 6Km / h

FUNCTIONS: Battery level indicator, backlight, odometer, pas levels.



FRONT FORK

TYPE OF FORK: Aluminum fork with mechanical suspension.



TYRES

TIRES: CHAOYANG 20“ x 4”

RIM: Alloy, 6 spokes, BAFANG

REAR HUB: With disc brake

FRONT HUB: With motor and disc brake.



GEARS

GEAR RATIO: 7 Speed

FRONT DERAILLEUR: No

REAR DERAILLEUR: SHIMANO Tourney / RD – TY300D

CONTROLS: SHIMANO ALTUS SL-M310

CROWN: Single, 1 speed, 48 teeth



BATTERY

CAPACITY: 48V 20.4AH

TYPE OF CELLS: Lithium Ion (Li-Ion) with PANASONIC elements

AUTONOMY (KM): 50 – 90 Km, it depends on the engine effort

CHARGING TIME: 8 hours (approximately)

CHARGING CYCLES: 1000 cycles (approximately)

PLACEMENT: External, saddle pad, removable

USB PORT: Yes.



OTHER COMPONENTS

SADDLE: Ergonomic, liftable

SEATPOST: Aluminum alloy with quick release

MUDGUARDS: Metal

HEADLIGHT: LED, can be activated from the handlebar

REAR LIGHT: LED with direction indicator, activated by handlebar

PEDALS: in ABS with aluminum body, foldable.



NOTES

Kickstand, 750W engine, wrinkle paint, BAFANG alloy wheels, TEKTRO hydraulic brakes





FRAME

MODEL: Fat-bike, folding

MATERIAL: aluminium alloy, 6061

SIZE: 20”

TOTAL WEIGHT: 29Kg (about)

AVAILABLE COLORS: Black, White, Green



HANDLEBARS

TYPE: In aluminum, with folding handlebar and adjustable height

HANDLEBAR: Riser bar.



BRAKES

BRAKE TYPE: Disc

FRONT BRAKE CALIPER .: Hydraulic, SHMANO

POST BRAKE CALIPER: Hydraulic, SHMANO

BRAKE LEVERS: In SHMANO aluminum.



MOTOR

MODEL: WTA Motor

TYPE: Brushless continuous current (Brushless)

POWER: 750 Watts

VOLTAGE: 48 Volts

LOCATION: Rear wheel.



CONTROLLER

MODEL: KEYDYSP KD51C-D (central display)

TYPE: Multifunction with LCD display

PAS LEVELS: 5 levels (speed)

CRUISE CONTROL: Yes, max 6Km / h

FUNCTIONS: Battery status indicator, backlight, odometer, pas levels.



FRONT FORK

Suspension fork with locking and unlocking system.



WHEELS

TYRE: CHAOYANG 20 * 2.125 ”

RIM: Aluminum, 34 holes with double reinforced chamber

ANT HUB .: with brake disc

REAR HUB: With engine and brake disc.



GEARS

TRANSMISSION REPORTS: 7 Speed MEGA RANGE posteriore

FRONT DERAILLEUR: Not present

REAR DERAILLEUR: SHIMANO Tourney / RD-TY300D

CONTROLS: SHIMANO SL-M310

CROWN: Aluminum, single, 1 speed, 48 teeth.



BATTERY

CAPACITY: 48V 13AH

CELL TYPE: Lithium Ion (Li-Ion) with EVE elements

AUTONOMY (KM): 30 – 60 Km depending on the engine effort

RECHARGING TIME: 6 – 8 hours (approximately)

RECHARGE CYCLES: 1000 cycles (approximately)

LOCATION: External, underseat, removable

USB PORT: Yes.



OTHER COMPONENTS

SADDLE: In “Gel”

SEAT POST: Aluminum alloy with quick release (ZOOM)

MUDGUARDS: Metal, steel (rust free)

HEADLIGHT .: LED, can be activated from the display

REAR LIGHT: LED, can be activated from the display

PEDALS: Folded, in ABS with aluminum body

Frequently Asked Questions

Aside from having great off-road performance, fat tyre eBikes are probably among the best for daily riding. The onboard motor means you no longer have to worry about the tyres higher rolling resistance. If your daily commute means having to travel over rough roads, you should really try a fat tyre electric bike.

Fat bikes are very comfortable. The large volume low pressure tires act as shock absorbers. Since the large tires absorb a lot of the vibration from riding, there is less stress on your hands and lower back.

At ebikesireland.com we have a strict policy, we only sell Italian DME Bikes. All of our bikes are hand assembled within Europe.





Yes of course, you can call or email to arrange a test ride, we can talk you through your requirements and offer expert advice as to which model to select.

Yes, not a problem, you can order the bike from the comfort of your own home. Just add everything to the basket and purchase in the normal way. Once the order has been placed, send us an email to arrange an appointment that suits you to visit us and collect the bike. We always allow enough time so we can further answer any questions you may have and to talk through the operation of the bike.

The Revenue rules say you can get new bicycles and pedelecs (electrically assisted bicycles which require some effort from the cyclist). The scheme does not cover: motorbikes, scooters or mopeds; second-hand bicycles or equipment; bicycle parts or associated equipment.



Treat an electric bike just the same as a normal bike. You can ride an electric assisted bike anywhere you can ride your regular bike. Be it on the road commuting to work or off road our all terrain e-bikes will get you there.



No it does not. Some manufacturers do advertise that the bikes regenerate whilst braking or going down hill. To be honest this is all talk.



All our electric bikes use lithium ion battery packs. These packs recharge quickly compared to others on the market. In general a 400Wh pack will take about 4.5 hours to recharge 100% from flat.

Generally speaking as long as you don't leave your battery for long periods of time completely empty and you top the battery up after each ride, this is all you need to do.



All ebikes are supplied with a key. Once the key is turned to the On position (assuming a battery is installed), the rider can twist the throttle to start riding the bike or start pedaling to engage the pedal assist system.

Ok This site requires cookies in order for us to provide proper service to you and our clients.
Read more

 Push Notifications are disabled

hide

e Bikes Ireland

 Add to homescreen

hide
